Output torque
- T2N : Up to 10,900 Nm
Frame Sizes (mm)
- 64/90/110/140/200/255/285/355/450
Ratios
- AHK (2 Stage)
- 12 / 15 / 16 / 20 / 25 / 28 / 35 / 40 / 49 / 50 / 70 / 100
- AHKA (3 Stage)
- 100 / 125 / 140 / 175 / 200 / 250 / 350 / 500 / 700 / 1,000
- AHKB (3 Stage)
- 64 / 84 / 100 / 125 / 140 / 175 / 200 / 250 / 280 / 350 / 400 / 500 / 700 / 1,000
- AHK (4 Stage)
- 1,225 / 1,400 / 1,750 / 2,000 / 2,800 / 3,500 / 5,000 / 7,000 / 10,000
- AHKC
- 2 Stage: 4 / 5 / 7 / 10
- 3 Stage: 21 / 31 / 46 / 61 / 91
Lowest Backlash – High Wear Resistance
- 2-stage : ≤2 arcmin (064 frame 3 arc min)
- 3-stage : ≤2 arcmin
- 4-stage : ≤2 arcmin
High Efficiency
- 2-stage : ≧ 94%
- 3-stage : ≧ 92%
- 4-stage : ≧ 90%
- 2-stage AHKC : ≧ 95%
- 3-stage AHKC : ≧ 93%
Easy mount
Low Noise
Compact structure
